5-MACHINE CNC & VMC FACILITY

A machine list that tells a customer exactly what you can make.

Divyana has a 5-machine CNC/VMC manufacturing base. The machines below are populated from the LMW machine purchase documents.

REQUEST A QUOTE →VIEW CAPABILITIES

DOCUMENTED CAPACITY

5 machines documented.

Purchase documents supplied for this build identify three LMW J2 VMC units, one LMW J6 VMC and one LMW LL20TL5 CNC lathe. Quantities are taken from those documents.

MACHINE 01 · J2 VMC

LMW J2 · Vertical Machining Centre

One of two J2 VMC units covered by the LMW purchase document with Mitsubishi control.

ControlMitsubishi M80VA Die & Mould

Spindle6,000 rpm belt-driven standard; 8,000 rpm direct-drive and 12,000 rpm BBT40 with chiller are also listed in scope

Tool changer24-tool twin-arm standard; 30-tool twin-arm option listed

CoolantSpindle coolant ring 60 lpm @ 4 bar; chip flush 300 lpm @ 1.5 bar listed

MotionPreloaded ball screws, absolute encoders on X/Y/Z, roller LM guideways

FunctionsRigid tapping, pitch-error and backlash compensation

The purchase scope lists standard and alternative spindle/ATC arrangements. Confirm the final installed configuration for this individual machine before publishing an option as fitted.

MACHINE 02 · J2 VMC

LMW J2 · Vertical Machining Centre

The second J2 VMC is included in the same LMW purchase document as Machine 01; the document specifies quantity two.

ControlMitsubishi M80VA Die & Mould

Spindle6,000 rpm belt-driven standard; 8,000 rpm direct-drive and 12,000 rpm BBT40 with chiller are also listed in scope

Tool changer24-tool twin-arm standard; 30-tool twin-arm option listed

CoolantSpindle coolant ring 60 lpm @ 4 bar; chip flush 300 lpm @ 1.5 bar listed

MotionPreloaded ball screws, absolute encoders on X/Y/Z, roller LM guideways

FunctionsRigid tapping, pitch-error and backlash compensation

The supplied document specifies two units under one scope. Individual nameplate/commissioning records should be used to distinguish any differences in the delivered setup.

LMW J2 vertical machining centre with tilting rotary table, machine 03

MACHINE 03 · J2 VMC · ROTARY AXES

LMW J2 · 4th & 5th Axis Configuration

A separate J2 purchase document lists additional rotary-axis equipment for this unit.

ControlMitsubishi M80VA Die & Mould

Rotary tableØ200 mm tilting rotary table (UCAM)

Axis equipment4th- and 5th-axis motor and drive, interface, connectors and cables

Column100 mm column extension; no extension to Z-axis stroke

Spindle scope6,000 rpm belt-driven standard; 8,000 rpm direct-drive and 12,000 rpm BBT40 with chiller are listed in scope

Tool changer24-tool twin-arm standard; 30-tool twin-arm option listed

CoolantSpindle coolant ring 60 lpm @ 4 bar; chip flush 300 lpm @ 1.5 bar listed

Rotary table and axis-interface details are specific to this J2 purchase document. Confirm final installed spindle and tool-changer setup from handover records.

MACHINE 04 · J6 VMC

LMW J6 · Vertical Machining Centre

One J6 CNC Vertical Machining Centre is identified in the supplied LMW purchase document.

ControlMitsubishi M80VA Die & Mould with 2,010-block look-ahead

Spindle6,000 rpm belt-driven standard; 8,000 rpm direct-drive and 12,000 rpm BBT40 with chiller are listed in scope

Tool changer24-tool twin-arm standard; 30-tool twin-arm option listed

CoolantSpindle coolant ring 60 lpm @ 4 bar; chip flush 300 lpm @ 1.5 bar listed

MotionPreloaded ball screws, roller LM guideways, pitch-error and backlash compensation

FunctionsRigid tapping, full enclosure, process-completion lamp and coolant-level indicator

The supplied scope lists standard and alternative spindle/ATC arrangements. Confirm the final installed configuration for this machine before presenting an option as fitted.

LMW LL20TL5 CNC turning machine, machine 05

MACHINE 05 · CNC TURNING

LMW LL20TL5 · CNC Lathe · FANUC

One LL20TL5 CNC lathe is identified in the supplied LMW purchase document.

ControllerFANUC 0i-TF Plus

Spindle speed3,500 rpm

Spindle power11 kW continuous / 15 kW for 15 minutes

Spindle noseA2-6

Bar capacityØ51 mm

Turret8-station vertically indexing hydraulic turret

ChuckØ200 mm, 3-jaw power-operated hollow chuck

TailstockMT-4 rotating centre with programmable quill in/out

Coolant60 lpm @ 4 bar

WHAT WE SHOW

Every machine gets the same engineering treatment.

Each card carries the actual make/model, working envelope, table, spindle, control, tooling, axis configuration and other useful production information from the supplied LMW machine purchase documents.

04VMC machines

03LMW J2 VMC units

01LMW J6 VMC unit

01CNC turning machine

Source discipline: machine quantities and configuration details on this page are taken from the LMW purchase documents you supplied. Manufacturer standard specifications are clearly marked with an asterisk. No unverified machine claims are presented as Divyana-specific capability.
